제품 상세 정보:
|
| 두께 범위: | 0.3-0.7mm | 소재 응력: | 235MPa 345MPa와 550MPa. |
|---|---|---|---|
| 롤러 재질: | No.45steel | 체계: | PLC는 자동 시스템을 제어합니다 |
Uncoiling the sheet ---- Sheet guiding ---- Straightening ---- Pre-cutting ---- Roll forming ---- Rectifying ---- post cutting ---- Panels to
Product:
We can also customize the products according to customer ' s requirements
Application:
Technical parameter
|
Suitable material |
color steel sheet;0.3-07mm, |
|
Working speed |
about10-25m/min |
|
stress |
235MPa,345MPa,550MPa. |
|
Power |
Main motor power: 5.5 Kw(Depend on final design) |
|
Hydraulic station power: 4Kw(Depend on final design) |
|
|
Material of forming rollers |
No.45 steel, plated with chrome on surface. |
|
Material of cutter,pressing die |
Cr12 mould steel with quench treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel, Roller grinder milling. |
|
Shaft diameter |
72mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Total weight of machine |
About 9500KGS |
|
Machine’s size |
about 18m×1.8m× 1.5m (Depend on final design) |
Our Roll Forming Machine’s advantages
1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .to protect surface shiniing and strong
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.and hardness 60 degree.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine. Rollers are CNC processed to ensure precision performance.
5 .automatic PLC : introduced Mitsubishi PLC with touch screen ,inverter,transformer.
6. powerful driving system: big inch train,or gear box driving system.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.
